Gulf

OASIS

Gulf

Autonomous Forklifts & Trucker

Gulf series AMR applies laser SLAM navigation to enable deployment and operation without modifying existing infrastructure. Multiple safety functions are integrated, including 360° full-area obstacle avoidance, spatial 3D obstacle avoidance, emergency stop buttons, and sounds and light alarms. In addition, the pallet detection sensors, anti-collision detectors, 3D vision cameras, RFIDs, and other multi-sensors are installed to achieve safe and efficient loading/unloading operations intelligently. Furthermore, high-current automatic charging ensures 24/7 operations, making the robots widely adopted in intelligent manufacturing and warehousing logistics. A self-developed Fleet Management System that is integrated into existing management systems such as MES, WMS, and ERP enables synchronous upgrades of intralogistics automation and production data informatization.

01. GULF 1400-CDD

General Description

Gulf 1400-CDD series unmanned smart-forklifts controlled by the Standard Robots Fleet Management System have made not only material transport automatic. Also, it adds detract value through loading more materials on the pallet per each round with up to 1400 kg of capacity. The Gulf-1400 forklifts use radar SLAM technology for their navigation system, along with 360-degree obstacle detection sensors and alerting systems to ensure maximum safety.

Max. Speed

1.5 m/s

Duration

8 hours

Payload

1400kg

Dimensions

1706*990*1836mm

Rotating Radius

1180mm

Top Reach

3000mm

02. GULF 1000 & 1500-CPD

General Description

Gulf 1000-CPD heavy-balance stacking forklifts are available in both 1000kg and 1500kg payload modules and have a top reach of 4.5m. These unmanned forklifts can be operated by manual control, adding new efficiencies across the facility, lowering costs and improving worker safety.

Max. Speed

1.5 m / s

Duration

8 hours

Payload

1000kg - 1500kg

Dimensions

2490*1166*2330mm

Rotating Radius

1264mm

Top Reach

4500mm

03. GULF 3000-QDD

General Description

The Gulf 3000 smart tractor were carefully picked from all the available options in the mobile robot market due to the heavy-duty features, flexible control system with our structural changes to the existing infrastructure and could be deployed quickly.

Max. Speed

2.8 m/s

Duration

8 hours

Payload

3000kg

Dimensions

1889*1038*1835mm

Applications

Storage Operations: Pallet stacking / Rack storage / Ground-level lines

cases

CASE STUDY

Internal Logistics Solution In New Material Industry

Efficient internal logistics for materials means improved productivity. The company cooperated with Standard Robots to upgrade the automation of intralogistics in production lines and invested in autonomous forklifts and mobile robots to replace the traditional AGVs, which handle all kiln cars in between processes.
CASE STUDY

Xingyu × Standard Robots | Join hands to create a benchmark mixed solution for intelligent logistics in the auto parts industry.

A mixed fleet of four autonomous mobile robots and two smart-forklifts works around the clock to improve material flows between the production line and storage.
CASE STUDY

8 robots automate the internal logistics of BAWEI Cosmetics Factory in China

Three Oasis autonomous mobile robots (AMR) and five Gulf smart-forklifts have boosted productivity, ensured safety, and dropped the error rate significantly at the BAWEI Plant, a company that focuses on the cosmetic OEM/ODM industry.
CASE STUDY

GULF-3000-QDD Streamlines Toyota's Largest Final Assembly Line

An automobile final assembly workshop is the single largest production hall in a car factory. The production line orchestrates over 3000 components and assembles 20 to 40 cars per every hour. Because of high value demands, the last 100 meters of the car parts staging area became critical for feeding the assembly line on time as well as efficiently. Also, the free-up human resources can be reconverting back into productive tasks and join with Toyota’s long term sustainability goal.
CASE STUDY

Smart Forklift Mass Delivery, Standard Robots Aids Futong Group on Logistics Automation

The smart forklift project launched by Standard Robots and Futong Group has garnered a significant amount of attention now that smart forklifts can fully automate work tasks.
