Transport Robots
Transport Robots
Solve the "last meter" breakpoint between devices
and achieve dynamic connection.

Transport Robots

Transport robots are widely used in material transfer between processes in industries such as 3C electronics, automotive, and photovoltaics. With high-precision SLAM navigation, they can accurately dock with equipment material inlets, achieving automated handling and transportation of various carriers such as Tray pans, Magazines, material boxes, pallets, and fixtures between devices. This effectively solves the automation challenge of the "last meter" breakpoint between devices caused by traditional manual handling. Operating continuously for 24 hours, they improve equipment utilization rates and significantly reduce labor costs and material waste, providing a reliable guarantee for factories to achieve full-process automated production and intelligence.

Products

OASIS-300E-SRT
OASIS-300E-SRT
A 50kg-rated (single-station load) differential drive single-station transport robot, which addresses the handling of carriers such as Tray pans, material boxes, cardboard boxes, baskets, and flat plate fixtures. It achieves unmanned transportation and automated loading and unloading between equipment material inlets and outlets, improving equipment utilization rates, enhancing on-site management, and significantly increasing the level of logistics automation and intelligence.
Max. Speed
1.5 m/s
Duration
8 Hours
Payload
50kg
Dimensions
890*620*957mm
Rotating Radius
543mm
OASIS-600E-SRT
OASIS-600E-SRT
A 50kg-rated (single-station load) differential drive dual-station transport robot, which addresses the handling of carriers such as Tray pans, material boxes, cardboard boxes, baskets, and flat plate fixtures. It achieves unmanned transportation and automated loading and unloading between equipment material inlets and outlets, improving equipment utilization rates, enhancing on-site management, and significantly increasing the level of logistics automation and intelligence.
Max. Speed
1.5 m/s
Duration
8 Hours
Payload
50kg
Dimensions
740*545*285mm
Rotating Radius
390mm
OASIS-1200E-SRT
OASIS-1200E-SRT
A 100kg-rated (single-station load) differential drive dual-station transport robot, which addresses the handling of carriers such as Tray pans, material boxes, cardboard boxes, baskets, and flat plate fixtures. It achieves unmanned transportation and automated loading and unloading between equipment material inlets and outlets, improving equipment utilization rates, enhancing on-site management, and significantly increasing the level of logistics automation and intelligence.
Max. Speed
1.5 m/s
Duration
8 Hours
Payload
100kg
Dimensions
1641*843*1400mm
Rotating Radius
920mm
OASIS-SMT-E1
OASIS-SMT-E1
Magazine differential drive single-station lifting transport robot, which addresses the handling of carriers such as Magazines and Tray pans in the factory for inter-process transportation. It achieves automated logistics between processes and material turnover in line-side buffer storage. Equipped with a lifting function for the transport module, it adapts to the inconsistent heights of equipment material inlets, reducing the need for adjustments to customer equipment. It also supports loading and unloading at both upper and lower material inlets, enabling the exchange of empty and full carriers.
Max. Speed
1.5 m/s
Duration
8 Hours
Payload
50kg
Dimensions
740*545*285mm
Rotating Radius
390mm
OASIS-SMT-E2
OASIS-SMT-E2
Magazine differential drive dual-station lifting transport robot, which addresses the handling of carriers such as Magazines and Tray pans in the factory for inter-process transportation. It achieves automated logistics between processes and material turnover in line-side buffer storage. Equipped with a lifting function for the transport module, it adapts to the inconsistent heights of equipment material inlets, reducing the need for adjustments to customer equipment. It also supports loading and unloading at both upper and lower material inlets, enabling the exchange of empty and full carriers.
Max. Speed
1.5 m/s
Duration
8 Hours
Payload
50kg
Dimensions
740*545*285mm
Rotating Radius
390mm
OASIS-SRT-500
OASIS-SRT-500
A 500kg-rated (single-station load) differential drive single-station transport tipping robot, which addresses the handling and tipping of heavy material boxes. It achieves automated transportation and feeding of raw materials, such as medicinal materials, without the need to change the existing feeding equipment of the customer, reducing the cost of equipment introduction.
Max. Speed
1.5 m/s
Duration
8 Hours
Payload
500kg
Dimensions
740*545*285mm
Rotating Radius
390mm
